SIMRAD AD80 ANALOG DRIVE INTERFACE

Part No:
000-10191-001
POA

Overview

Drive interface for analog or proportional control of rudder or thruster using analog voltage or low level current with possibility for frequency, voltage or current angle feedback, digital drive handshake and external mode input.

Includes:

  • UI CRTL - output for analog voltage low current command
  • RUD UI - Input for analog (voltage or current) rudder feedback
  • RUD FRQ - Input for frequency rudder feedback
  • READY - output for ready contact when board is up running ready for control
  • HS1 - Generic in/out handshake signal port 1
  • HS2 - Generic in/out handshake signal port 2
  • MODE - Input for external mode selector
  • SIMNET - connection to CAN network
