Actisense Micro gender changer (male to male) 0.25 metre cable

Part No:
A2K-GCM-0M25
POA

Overview

Actisense Micro gender changer (male to male) 0.25 metre, UL certified cable

A2K-GC Lite Gender Changer Cables
Use between two cable connectors of the same type and gender of connector on an NMEA 2000® backbone.
Manufactured using Actisense designed connectors with 0.25m UL certified cable, the gender changers offer easy and secure connections.

The gender changers are available in male and female versions.

The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.

For Actisense trunk drop cable (TDC) assemblies in various lengths, please visit the A2K-TDC page.

To order the Lite Gender Changer Cables, please use the following product codes:

A2K-GCF-0M25 Lite gender changer (female to female), 0.25 metre UL certified cable
A2K-GCM-0M25 Lite (male to male) 0.25 metre UL certified cable

A2K-GC Lite Gender Changer Cables

Use between two cable connectors of the same type and gender of connector on an NMEA 2000® backbone.

Manufactured using Actisense designed connectors with 0.25m UL certified cable, the gender changers offer easy and secure connections.

The gender changers are available in male and female versions.

The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.

For Actisense trunk drop cable (TDC) assemblies in various lengths, please visit the A2K-TDC page.

Electrical
Rated Current 3A
Rated Voltage



 60VDC


Mechanical
Male Contact Brass, gold plated
Female Contact Phosphor bronze, gold plated
Contact Carrier PA66 (30% Glass filled), black
Contact Polarisation Standard M12 -“A”- polarisation
Mating Thread M12
Screw Cap Brass, nickel plated
O-Ring Seal Rubber, black
Housing PVC, black
Power Pair 22 AWG (19 strand tinned copper)
Data Pair 24 AWG (19 strand tinned copper)
Drain 22 AWG (19 strand tinned copper)
Braid 37 AWG (tinned copper)
Jacket Material 0.8mm Nom. PVC, black
Jacket Outer Diameter 6.85mm ±0.254mm
Weight 50g
Length



 0.25m


Approvals and Certifications
Protection IP67 (when mated)
Operating Temperature -25°C to +70°C
Storage Temperature -40°C to +85°C
NMEA 2000 Approved
RoHS Compliant
UL Certified (E137250), (UL1277)
