XSONIC AIRMAR CM599LH-W

Part No:
000-13941-001
POA

Overview

Get more coverage under your boat with Airmar’s unique wide-beam, high-frequency, Chirp-ready transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high-frequency band results in superior resolution. The constantly wide beam provides twice the coverage and excellent fish arches on the display compared to most high-frequency, narrow-beam transducer options.

The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat is essential down to 152 m (500').

The low-frequency band is rated to 3 kW and produces amazing deep-water performance to 3,048 m (10,000'). Get the best of both worlds with Airmar’s dual-frequency, Chirp-ready transducer with wide-beam coverage.

Features:

Depth and fast-response water-temperature sensor.
3 kW for superior deep-water performance.
3 kW low frequency: 28 to 60 kHz.
23° to 9° port-starboard beamwidth.
11° to 5° fore-aft beamwidth.
Maximum depth performance to 3,048 m (10,000').
1 kW high frequency: 150 to 250 kHz.
25° constant beamwidth.
Maximum depth of 152 m (500').
132 kHz of total bandwidth from one transducer.
Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth.
High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation.
High wide beamwidth yields more coverage for detecting fish in the upper-water column.
Urethane housing with Curved-edge Design for wet-box installation.
Also available as an external (R509LHW) mount.

Features



  • Depth and fast-response water-temperature sensor
  • 3 kW for superior deep-water performance
  • 3 kW low frequency: 28 to 60 kHz
    • 23° to 9° port-starboard beamwidth
    • 11° to 5° fore-aft beamwidth
    • Maximum depth performance to 3,048 m (10,000')
  • 1 kW high frequency: 150 to 250 kHz
    • 25° constant beamwidth
    • Maximum depth of 152 m (500')
  • 132 kHz of total bandwidth from one transducer
  • Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
  • High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation
  • High wide beamwidth yields more coverage for detecting fish in the upper-water column
  • Urethane housing with Curved-edge Design for wet-box installation
  • Also available as an external (R509LHW) mount
  • Exclusive Xducer ID® technology

Specifications



  • Weight: 14.2 kg (31.2 lb.)
  • Recommended Boat Length: 8 m (25') and above
  • Hull Material: Solid fiberglass or steel
  • Hull Deadrise: Accommodates any deadrise angle based on custom-cavity or welded-tank construction
  • Acoustic Window: Urethane
  • Transducer Element: 25 internal broadband ceramic assemblies
